SKiiP 81AN15T1, Semikron, Integrated Intelligent Power Module
SKiiP 81AN15T1, Semikron, Integrated Intelligent Power Module
SKU: SKIIP-81AN15T1-SEMIKRON-INTEGRATED-INTELLIGENT-POWER-MODULE
Regular price
$46.00
Regular price
Sale price
$46.00
Unit price
per
Couldn't load pickup availability
SKiiP 39ANB16V1 IGBT Module
Product Information
| Parameter | Value |
|---|---|
| Product Name | SKiiP 39ANB16V1 |
| Type | IGBT Module with Rectifier Bridge |
| Manufacturer | Semikron-Danfoss |
| Package | MiniSKiiP II 3 |
| Part Number | 25230180 |
| Product Status | In production |
| Dimensions (L×W×H) | 82×59×16 mm |
Key Specifications
| Category | Parameter | Value | Units | Notes |
|---|---|---|---|---|
| Maximum Ratings | Collector-Emitter Voltage (VCE) | 1600 | V | Max |
| Continuous Collector Current (IC) | 124 | A | @ Tj=125°C | |
| Surge Current (IFSM) | 1600 | A | 10ms pulse | |
| Junction Temperature (Tj) | -40 to +150 | °C | Max | |
| Electrical Characteristics | Forward Voltage Drop (Vf) | 1.5 | V | Typical, IF=124A |
| Reverse Recovery Charge (Qrr) | 150 | μC | Typical | |
| Switching Frequency | 20 | kHz | Typical |
Functional Capabilities
- High Voltage Handling: Supports up to 1600V for industrial power systems.
- High Surge Current Tolerance: 1600A surge capability for short-circuit protection.
- Low Forward Voltage Drop: 1.5V reduces conduction losses.
- Fast Switching: Optimized for 20kHz operation in high-frequency applications.
Technical Features
- Fast Trench IGBT Technology: Reduces switching losses and improves efficiency.
- Robust Freewheeling Diodes: CAL (Carrier Life Control) technology ensures soft recovery.
- Spring Contact Connections: Reliable electrical connections with vibration resistance.
- Integrated Rectifier Bridge: Simplifies inverter input stage design.
Application Areas
- Industrial Inverters: Input bridge for drives up to 45kVA.
- Renewable Energy: Solar and wind power converters.
- Motor Control: AC motor drives in pumps, fans, and compressors.
- Power Electronics: High-voltage DC-DC converters.
This product brief is generated by AI based on the provided documentation. For precise technical details, please refer to the official datasheet. The information presented here is for general reference only and may not cover all specifications or updates
