AA121SL01, Mitsubishi, Display Module

AA121SL01, Mitsubishi, Display Module

SKU: AA121SL01-MITSUBISHI-DISPLAY-MODULE

$70.00
$70.00
Sale Sold out

RuffRuff App RuffRuff Apps by Tsun

Product Information

Item Details
Product Model AA121SL01
Product Name 12.1” Color TFT-LCD Module
Manufacturer Mitsubishi Electric Corp.
Display Area 246.0(H)×184.5(V) mm (12.106-inch diagonal)
Number of Dots 800×3(H)×600(V)
Pixel Pitch 0.3075(H)×0.3075(V) mm
Module Size 280.0(W)×210.0(H)×12.0(D) mm
Module Mass 720 g
Backlight Unit CCFL, 2-tubes, edge-light, replaceable

Key Specifications

Category Parameter Value Unit Remarks
Absolute Maximum Ratings Power Supply Voltage for LCD (VCC) 0 - 6.0 V
Logic Input Voltage (VI) -0.3 - 6.5 V Lamp Voltage (VL) 0 - 2000 Vrms Lamp Current (IL) 0 - 18 mArms Lamp Frequency (FL) -- - 80 kHz Operation Temperature(Panel) -20 - 70 °C Measured at the center of active area and at the center of panel back surface
Top, Tstg ≤40°C: 90% RH max. without condensation; Top, Tstg > 40°C: Absolute humidity shall be less than the value of 90%RH at 40°C without condensation		 Storage Temperature -20 - 80 °C
Electrical Characteristics Power Supply Voltage for LCD (3.3V powered) 3.0 - 3.3 - 3.6 V
Power Supply Voltage for LCD (5.0V powered) 4.5 - 5.0 - 5.5 V Power Supply Current for LCD (3.3V powered) -- - 340 - 500 mA Typical current condition: 64-gray-bar pattern, 600 line mode, VCC=+3.3V, fH=37.9kHz, fV=60.3Hz, fCLK=40MHz Power Supply Current for LCD (5.0V powered) -- - 220 - 340 mA Typical current condition: 64-gray-bar pattern, 600 line mode, VCC=+5.0V, fH=37.9kHz, fV=60.3Hz, fCLK=40MHz Permissive Input Ripple Voltage (VRP) -- - -- - 100 mVp-p VCC = +3.3V/5.0V Logic Input Voltage High (VIH) 2.0 - -- - 5.5 V Logic Input Voltage Low (VIL) 0 - -- - 0.8 V Lamp Voltage (VL) -- - 540 - -- Vrms IL=12.0 mArms Lamp Current (IL) 6.0 - 12.0 - 14.0 mArms Lamp Frequency (FL) 30 - - 60 kHz Starting Lamp Voltage (Ta = 25°C) 1000 Vrms Starting Lamp Voltage (Ta = 0°C) 1200 Vrms
Optical Characteristics Contrast Ratio (CR) 350 - 500 - Ta=25°C, VCC=3.3V/5.0V, θV=0°, θH=0°
Luminance (Lw) 250 - 400 - -- cd/m² Ta=25°C, VCC=3.3V/5.0V, θV=0°, θH=0° Luminance Uniformity (ΔLw) -- - - 30 % Ta=25°C, VCC=3.3V/5.0V, θV=0°, θH=0° Response Time (tr) -- - 10 - ms Ta=25°C, VCC=3.3V/5.0V, θV=0°, θH=0° Response Time (tf) -- - 30 - ms Ta=25°C, VCC=3.3V/5.0V, θV=0°, θH=0°
