6ES7136-6DB00-0CA0, Siemens, PLC
6ES7136-6DB00-0CA0, Siemens, PLC
SKU: 6ES7136-6DB00-0CA0-SIEMENS-PLC
Regular price
$206.00
Regular price
Sale price
$206.00
Unit price
per
Couldn't load pickup availability
Product Information
| Item | Details |
|---|---|
| Product Model | 6ES7136-6DB00-0CA0 |
| Product Description | SIMATIC DP, Electronics module for ET 200SP, F-DQ 4x24 V DC/2A, 15 mm width, up to PL E (ISO 13849) up to SIL 3 (IEC 61508) |
| Product Family | Digital F-output modules |
| Product Lifecycle | PM300: Active Product |
| Net Weight | 0.064 kg |
| Packaging Dimensions | 6.90 x 7.50 x 2.90 cm |
| Country of Origin | Germany |
Key Specifications
| Category | Parameter | Value | Unit | Description |
|---|---|---|---|---|
| Electrical Parameters | Output Voltage | 24 V DC | V | Rated output voltage |
| Number of Channels | 4 | - | Total digital output channels | |
| Output Current per Channel | 2 | A | Maximum current per output channel | |
| Physical Specifications | Module Width | 15 | mm | Width for space-efficient installation |
| Mounting Type | For ET 200SP | - | Compatibility with Siemens ET 200SP system | |
| Safety Ratings | Performance Level (PL) | E (ISO 13849) | - | Highest safety performance level |
| Safety Integrity Level (SIL) | 3 (IEC 61508) | - | Highest safety integrity level | |
| Compliance | RoHS Compliance | Yes (Since 08.08.2013) | - | Conforms to Restriction of Hazardous Substances directive |
Functional Capabilities
- Safety-Critical Outputs: Provides 4 isolated 24 V DC/2A digital output channels for safety-related applications requiring reliable signal transmission.
- Advanced Safety Standards: Meets PL E (ISO 13849) and SIL 3 (IEC 61508), ensuring compliance with stringent industrial safety requirements.
- Compact Design: 15 mm width enables space-efficient installation in modular automation systems like ET 200SP.
- High-Reliability Operation: Designed for fail-safe performance, maintaining safe states during faults or power disruptions.
Technical Features
- Fail-Safe Architecture: Ensures safe output states during malfunctions, critical for emergency stop and safety interlock systems.
- Modular Compatibility: Seamlessly integrates with Siemens ET 200SP distributed I/O system for flexible system expansion and configuration.
- Industrial-Grade Construction: Built to withstand harsh industrial environments, though specific environmental specs (e.g., temperature, humidity) are not detailed in the provided data.
Application Areas
- Industrial Automation: Used in machinery, production lines, and control systems requiring safety-certified signal output.
- Safety-Critical Systems: Ideal for emergency stop circuits, safety relays, and hazard mitigation in manufacturing plants.
- Process Control: Integrates with distributed I/O systems for real-time safety-oriented control and monitoring.
- Machine Tools: Supports precision output control in CNC machines and automated equipment with strict safety requirements.
Disclaimer
This product brief is generated by AI based on information from the Siemens Industrial Mall webpage. While the technical specifications and safety ratings are derived directly from the product data, details such as environmental operating conditions, diagnostic functions, and extended compatibility may be incomplete. Always consult the official Siemens datasheet for precise technical documentation, installation guidelines, and compliance information. This summary is for general reference only and does not guarantee product performance or availability.
