6AV2124-0JC01-0AX0, Siemens, SIMATIC HMI KTP400 basic PN Compact Panel
6AV2124-0JC01-0AX0, Siemens, SIMATIC HMI KTP400 basic PN Compact Panel
SKU: 6AV2124-0JC01-0AX0-SIEMENS-SIMATIC-HMI-KTP400-BASIC-PN-COMPACT-PANEL
When you see these red characters, it means that these prices are not transaction prices, they are for reference only. We will not accept the payment if you pay directly without getting a quote from us.
How to get a price and buy this product?
Method A: You can send a message, then we will contact you. After we update the latest price, then you can make an order.
Method B: You can add this product into the cart and complete the order without paying. Then we will contact you and you can make payment after we send you a new order with an updated price.
Couldn't load pickup availability
Product Information
- Product Name: SIMATIC HMI KTP400 basic PN Compact Panel
- Model: 6AV2124 - 0JC01 - 0AX0
- Product Description: Features a 4 - inch widescreen color display with a resolution of 480 x 272 pixels, supports communication via Profinet interface, suitable for industrial automation human - machine interaction applications.
- Product Lifecycle: PM300: Active Product
- Country of Origin: Germany
- Net Weight: 0.580 kg
- Package Dimensions: 230×150×75 mm
- Estimated Delivery Time: 3 working days
Key Specifications
| Parameter Category | Parameter Details |
|---|---|
| Display | Size: 4 - inch widescreen Resolution: 480 x 272 pixels Colors: 256 colors |
| Communication Interface | Profinet interface |
| Power Supply Voltage | 24 V DC (-15%/+20%) |
| Protection Class | Front panel: IP65 Back: IP20 |
| Operating Temperature Range | -20°C to 60°C |
| Storage Temperature Range | -25°C to 70°C |
| Relative Humidity | 10% - 95% (no condensation) |
Functional Capabilities
- Supports rich graphical interface design to create intuitive operation screens.
- Enables fast communication with industrial controllers via the Profinet interface.
- Has data recording and alarm functions for easy monitoring of industrial processes.
Technical Features
- Adopts a 4 - inch widescreen color display for good visual effects.
- Supports the Profinet communication protocol for high - efficiency communication.
- Has a wide operating temperature range to adapt to different industrial environments.
Application Areas
Note: The application areas are not specified in the document, so this section is omitted due to missing information.
Disclaimer
This product introduction is generated by artificial intelligence for reference only. The content is compiled based on publicly available information and may contain omissions or errors. For specific technical parameters, scope of application, and compliance requirements, please refer to the official documentation or product manual published by Siemens. For accurate information or professional technical support, please contact the Siemens customer service team.
